Copper Nickel Tube and Pipe Cu-Ni ASME B36.19M UNS C70600 (90/10) UNS C71600 (70/30)
Specifications
| Type | Copper Nickel Tube and Pipe Cu-Ni | Application | Air Condition Or Refrigerator | Specification | C70600/CuNi10Fe1Mn/CN102 |
| Outer Diameter | Air Condition Or Refrigerator | Thickness | 0.15 - 15mm | Length | 0.5 - 25 m |
| Cu (Min) | 90% | Alloy Or Not | Is Alloy | Wall Thickness | 0.15 - 15mm |
| Outside Diame | 3 - 260mm | Model Number | ASTM B111/EN12451/DIN17 | Place of Origin | Shanghai, China (Mainland) |
Packaging & Delivery
Packaging Details: Polywood case
Delivery Detail: 15 days after confirmed order
COPPER-NICKEL SEAMLESS & WELDED PIPE & TUBE
| TYPE | STANDARD | CODE |
| SEAMLESS | ASTM | (UNS C70400) B466 |
| (UNS C72200) B466 |
| ASME | (UNS C70600) SB466 |
| (UNS C71000) SB466 |
| (UNS C71500) SB466 |
| WELDED | ASTM | (UNS C71500) SB467 |
| ASME | (UNS C70600) SB467 |
Nickel alloys seamless tube factory price NI200, copper nickel pipe price
1.Style: Nickel Tube Ni200
2.Grade: N4 /N6
3.Standard: ASTM B161
4.Certification: ISO9001 : 2008
5. Purity: 99.6%min
6. Feature:
| Ingredient | Ni | Mn | Fe |
| Content | 99.5 | 0.10 | 0.15 |
| Skin material specification | Thickness | ≥0.1mm |
| Width | According to customers demand |
| Silk material specification | ≥0.1mm |
| Tensile strength | ≥43kgf/mm2 |
| Elongation ratio (L=100) | ≥15 |
| Characteristic and use | It is an alloy product with nickel as the essential component. It has the fine mechanical strength, corrosion resistance performance and characteristic of high strength under high temperature. It is applied in manufacturing electronic vacuum devices, electronic instrumentation parts and so on. |
7. Application:
-----for electronic vacuum
-----fine mechanical strength
-----good corrosion resistance performance
-----high heat-resistan
8.Physical properties
| Grade | Tensile strengh,min,Mpa | Yield Strength,0.2% offset,Mpa | Elongation,min% |
| | M | m | M | m | M | m |
| Nickel 200 | 379 | 448 | 103 | 267 | 40 | 15 |
| Nickel 201 | 345 | 414 | 83 | 207 | 40 | 15 |
| Monel400 | 483 | 586 | 193 | 375 | 35 | 15 |
9.Compare with 201 and 200 in properties and chemical composition
Properties
| | Density | Melting point | Coefficient of expansion | Modulus of rigidity | Modulus of elasticity | Electrical resistivity |
| Ni200 | 8.9g/cm3 | 1446°C | 13.3 µm/m °C (20-100°C) | 81kN/mm2 | 204kN/mm2 | 9.6μW• cm |
| Ni201 | 1446°C | 13.1µm/m °C(20-100°C) | 82kN/mm2 | 207kN/mm2 | 8.5μW• cm |
Chemical Composition
| Grade | Element Composition/% |
| Ni+Co | Mn | Cu | Fe | C | Si | Cr | S |
| Ni201 | ≥99.0 | ≤0.35 | ≤0.25 | ≤0.30 | ≤0.02 | ≤0.3 | ≤0.2 | ≤0.01 |
| Ni200 | ≥99.0 | /≤0.35 | ≤0.25 | ≤0.30 | ≤0.15 | ≤0.3 | ≤0.2 | ≤0.01 |
