Brand Name : TOBO/TPCO/TISCO/VALIN/METAL
Model Number : Copper Nickel Tube
Certification : ISO/PED/TUV/SGS/LR/BV
Place of Origin : China/Japan/Germany
MOQ : 1pc
Price : USD Depending on quantity
Payment Terms : L/C, T/T, Western Union
Supply Ability : 3,0000pcs per month
Delivery Time : 10-100 days depending on quantity
Packaging Details : PLY-WOODEN CASE OR PALLET
Size : 1-96 inch
Material Grrade : Copper Nickel Elbolet: C70600(90:10), C71500 (70:30), C71640
DN : 15-2400
Type : Seamless or weld
OD : 10-600mm
thickness : 0.5-50mm
Copper Nickel Tube C70600, Cu-Ni Weldolet C70600(90:10), C71500 (70:30), C71640
1) Grade : C71500 C70600
2) Diameter :10mm-55mm
3) Wall thickness : 0.5mm-3mm
4) Length : 1000mm-8000mm
5)Temper: soft ,Hard
Nickel -Copper Tube :
We produce the tubes at different diameters, wall thicknesses and lengths according to your specific requirements.
Specification of Nickel-Copper Tube:
1) Grade:C71500 C70600
2) Diameter: 10mm-55mm
3) Wall thickness: 0.5mm-3mm
4) Length: 1000mm-8000mm
5) Temper:Soft, Half Hard ,Hard
More detailed imformation as the following table:
Grade | Temper | Section Size (mm) | Length | |
Outer Diameter | Wall Thickness | |||
CuNi30Mn1Fe | Soft | Φ12 ~ 55 | 0.75-3.0 | 1000 ~ 8000 |
Half Hard | Φ10 ~ 50 | 0.75-3.0 | 1000 ~ 8000 | |
Hard | Φ10 ~ 50 | 0.75-3.0 | 1000 ~ 8000 | |
CuNi10Fe1Mn | Soft | Φ12 ~ 55 | 0.5-3.0 | 1000 ~ 8000 |
Half Hard | Φ10 ~ 50 | 0.75-3.0 | 1000 ~ 8000 | |
Hard | Φ10 ~ 50 | 0.75-3.0 | 1000 ~ 8000 |
1) Superior quality copper nickel pipes
2) Offer a wide range of copper Tubes,pipes
4) Grade:C70600 (90/10) & C71500 (70/30)
Description Of The Products :
Table 1 : Mechanical Properties
Temper | JIS Temper | Tensile Strength Rm/N/mm 2 | Elongation A50/% | Hardness HV |
M | O | 310~410 | ≥ 30 | 40~60 |
Y2 | 1/2H | 320~450 | ≥ 20 | 55~85 |
Y | H | 440~480 | - | 80~150 |
T | EH | 450~540 | - | - |
Table 2 : Alloy Number
Name | GB | ALLOY NO. | SIZE (mm) | ||||
(ISO) | (ASMT) | (JIS) | (BIS) | (DIN) | |||
Copper Foil | T2 | Cu-ETP | C11000 | C1100 | C101 | R-Cu57 | Thickness: 0.006-0.1 /Max Width: 650 |
Table 3 : Size & Tolerance
Thickness | Thickness Tolerances | Width | Width Tolerances |
0.006~0.04 | ± 0.001 | 1.0~650 | ± 0.1 |
> 0.04~0.10 | ± 0.002 |
Table 4 : Specifications
Thickness | Width | Temper |
0.006~0.04 | 1.0~650 | O,1/2H,H,EH |
> 0.04~0.10 | 1.0~650 | O,1/2H,H,EH |
![]() |
Seamless Copper Nickel Tube C70600 Cu - Ni Weldolet C70600(90:10) C71500 (70:30) C71640 Images |
